ESAB - ROGUE EM140 120V MIG SYSTEM W LED - 0700301082

ESAB Rogue EM140 MIG/Flux Core Welding Machine

ESAB Rogue EM 140 is an inverter-based MIG/MAG welding system designed to address all your welding project needs, from light fabrication to repair and maintenance. The system features industrial-grade arc performance and full featured controls that allow the welder to fine tune arc characteristics based on the material they are welding. With a weight of only 13 kg (28.8 lbs), single voltage 120V single-phase input and compatibility with 6 kVA (4.8kW) generators, this system provides maximum flexibility and portability, both in the shop and in the field.

Specifications

Input Voltage          120 VAC ±10 %, 1, 50/60 Hz

GMAW Welding Output      90 A18.5 V @ 30% Duty Cycle

               64 A 17.2 V 60% Duty Cycle

               49 A16.5 V @ 100% Duty Cycle

Current Range          30-140 A

Voltage Range          12-22 V

Wire Feeder Specifications    2.0-11.4m/min (75-450 in./min)

Open Circuit Voltage       50 VDC

Wire Diameter

Mild Steel            0.6-0.9 mm (0.023-0.035in)

Stainless Steel          0.6-0.9 mm (0.023-0.035in)

Cored Steel           0.8-0.9 mm (0.030-0.035in)

Aluminum            0.8-0.9 mm (0.030-0.035in)

Max Spool Diameter       100 & 200 mm (4 & 8 in.)

Power Factor at Maximum Current 0.80

Efficiency at Maximum Current  82.7%

Energy Save Mode        <50 W

Operating Temp         -10 to +40 C (+14 to +40 F)

Enclosure Class         IP23S

Certification Mark        cETLus

Dimensions

L x W x H             590 x 220 x 385 mm (23.2 x 8.7 x 15.2 In.)

Weight             13.1 kg ( 28.8 lb)

Setting Range          12.0-22.0 V (30-140 A)
