ESAB - RENEGADE VOLT ES200I SYSTEM NA - 0447800880
ESAB Renegade VOLT ES 200i Battery Powered Welding Machine + 4 Batteries
ESAB Renegade VOLT™ ES 200i is a portable, cordless battery powered, Stick (SMAW) and Live TIG (GTAW) welder with the versatility to operate in Battery, Mains, or AMP+ Hybrid Mode.
This cordless welder runs on 6 Ah, 9 Ah, and 12 Ah DEWALT® FLEXVOLT® batteries. Renegade VOLT provides the power to burn up to 33 (E6013) electrodes on a single charge using four 12 Ah batteries, that are included in the package.*
Renegade VOLT is a highly portable and powerful unit perfect for mobile welders operating in remote, offsite, or hard-to-reach locations without easy access to AC mains power.
In AMP+ Hybrid Mode, Renegade VOLT supplements AC mains power with battery power to prevent nuisance trips on smaller breaker sizes (e.g., 10A, 16A) or to provide more output when welding on 120V input.
Renegade VOLT features a rugged industrial design with durable, impact-resistant housing and multiple lift points for easy operation and transport in the field. The bright, intuitive color-screen user interface is designed for outdoor use, even in direct sunlight, and features a battery status display and remaining arc time calculator.
This powerful welder offers the highest arc quality with special features that include hot start, arc force, memory storage, and cellulosic mode (6010) to optimize performance based on application or user preference.
| Specifications |
Input Voltage 120/130 VAC 15%, 1 Φ, 50/60 Hz
GWAT (AC) Welding Output 140 A15.6 V (120 V) @ 25% Duty Cycle
90 A 13.6 V (120 V) @ 60% Duty Cycle
70 A12.8 V (120 V) @ 100% Duty Cycle
200 A18.0 V (230 V) @ 25% Duty Cycle
129 A15.2 V (230 V) @ 60% Duty Cycle
100 A14.0 V (230 V) @ 100% Duty Cycle
GRAW (AMP+) Welding Output 180 A17.2 V (120 V) @ 25% Duty Cycle
130 A15.2 V (120 V) @ 60% Duty Cycle
100 A14.0 V (120 V ) @ 100% Duty Cycle
200 A18.0 V (230 V) @ 25% Duty Cycle
129 A15.2 V (230 V) @ 60% Duty Cycle
100 A14.0 V (230 V) @ 100% Duty Cycle
GTAW (DC) Welding Output 150 A16.0 V (80V) @ 18% Duty Cycle
115 A14.6 V (80 V) @ 25% Duty Cycle
90 A13.6 V (120 V) @ 60% Duty Cycle
70 A12.8 V (80 V) @ 100% Duty Cycle
SMAW (AC) Welding Output 110 A24.4 V (120 V) @25% Duty Cycle
70 A22.8 V (120 V) @ 60% Duty Cycle
55 A22.2 V (120 V) @ 100% Duty Cycle
200 A28.0 V (230 V) @ 25 % Duty Cycle
129 A25.2 V (230 V) @ 60% Duty Cycle
100 A24.0 V (230 V) @ 100% Duty Cycle
SMAW (DC) Welding Output 150 A26.0 V (120 V) @ 25% Duty Cycle
90 A23.6 V (120 V) @ 60% Duty Cycle
70 A22.8 V (120 V) @ 100% Duty Cycle
200 A28.0 V (230 V) @ 25% Duty Cycle
129 A25.2 V (230 V) @ 60% Duty Cycle
100 A24.0 V (230 V) @ 100% Duty Cycle
SMAW (DC) Welding Output 140 A25.2 V (80 V) @ 18% Duty Cycle
110 A24.4 V (80 V) @ 25% Duty Cycle
80 A23.2 V (80 V) @ 60% Duty Cycle
60 A22.4 V (80 V) @ 100% Duty Cycle
90-270 VAC
Open Circuit Voltage 80 VDC
Power Factor at Maximum Current 0.99
Efficiency at Maximum Current 80%
Fuse Slow 16 A
Energy Save Mode <50 W
Supply Plug NEMA 6-50P (CSA)
Operation Temp -10 to +10 C (+14 to +104 F)
Rated kVA 2.7 kVA (120 V)
6.0 kVA (120 V)
Enclosure Class IP23
Certification Mark ETL
Dimensions, L x W x H
Power Source and Battery Box 19 kg (41 lbs)
Power Source, Battery Box, 4 Battery Packs* 24.5 kg (54 lbs)
Setting Range
AMP+ 20.6-28 V (10-200 A)
DC 20.6-25.6 V (10-140 A)
AC 10.4-18 V (10-200 A )
AC 20.6-28 V (10-200 A)
AMP+ 20.6-26 V (10-150 A)
AMP+ 10.4-17.2 V (10-180 A)
DC 10.4-16 V (150 A)
AC 20.6-24.4 V (10-110 A)
AMP+ 10.4-18 V (10-200 A)
AC 10.4-17.2 V (10-180 A)
*based on standard operating conditions
